DRAWING-LED FASTENERS
J-Shaped Anchor Bolts
J-Shaped / Umbrella Bend for project-defined connections, with dimensions, material and matched components specified for the installation.
SPECIFICATIONS & CUSTOMIZATION
Define The Geometry.
Define the dimensions and connection requirements together on the product drawing or schedule.
Dimensions & Configuration
- Rod Diameter · d
- M12–M64; other diameters to drawing
- Overall Height · L
- Overall outside height including the hook
- Inside Hook Width · C
- Clear inside width between the long and return legs
- Thread Length · b
- Exposed thread length, pitch and tolerance
- Return Length · h
- Straight return length from bend tangent to free tip
- Inside Radius · R / Bend Angle · α
- 180° round return as illustrated; inside radius and any alternative angle to drawing
Material & Grade
Specify the steel material and mechanical requirements for the selected product form.
Drawing & Connection
Include dimension references, tolerances and the mating connection or installation detail.
Surface & Fit
Specify the surface condition and protection for the installation environment, including mating thread fit.
COMPONENTS & INSPECTION
Define The Complete Supply Requirement.
Matched Components
Include the components required by the connection drawing.
- Nuts, washers and accessories by item and quantity
- Identification against the product schedule
- Packing and handling protection for delivery
Inspection Requirements
Define acceptance criteria for the product and connection.
- Dimensions and drawing-specific geometry
- Material and mechanical requirements
- Surface condition, threads and inspection records
HAVE A DRAWING?
Have A Foundation Detail?
Send the dimensioned drawing, material / grade, finish, quantity and required installation hardware.
