DRAWING-LED FASTENERS
Embedded Plate Assemblies
Plate With Welded Anchors for project-defined connections, with dimensions, material and matched components specified for the installation.
SPECIFICATIONS & CUSTOMIZATION
Define The Geometry.
Define the dimensions and connection requirements together on the product drawing or schedule.
Dimensions & Configuration
- Plate Dimensions
- Length, width, thickness and hole pattern
- Anchor Arrangement
- Rod / stud count, diameter and spacing
- Assembly Height
- Projection, embedment and alignment
- Weld Requirements
- Weld sizes and joint preparation to drawing
- Tolerances
- Flatness, anchor position and assembly squareness
Material & Grade
Specify the steel material and mechanical requirements for the selected product form.
Welds & Assembly
Specify weldability, joint configuration, weld size and alignment tolerances. Include the required weld inspection scope.
Surface & Fit
Specify the surface condition and protection for the installation environment, including mating thread fit.
COMPONENTS & INSPECTION
Define The Complete Supply Requirement.
Matched Components
Include the components required by the connection drawing.
- Nuts, washers and accessories by item and quantity
- Identification against the product schedule
- Packing and handling protection for delivery
Inspection Requirements
Define acceptance criteria for the product and connection.
- Dimensions and drawing-specific geometry
- Material and mechanical requirements
- Surface condition, threads and inspection records
HAVE A DRAWING?
Have A Connection Detail?
Send the dimensioned drawing, material / grade, finish, quantity and required installation hardware.
